Balance, Analytical, Touchscreen, 310g x 0.1mg, External Calibration, 100-240V, 50-60Hz
In stock
Balance, Analytical, Touchscreen
The Series of Analytical and Precision Balances offer a wide range of options, making them an essential piece of equipment in any laboratory.
These balances have an advanced color touch display for ease of use, and include touch-free operation capability with two infrared sensors. Intelligent design features like a customizable home screen, and extensive onboard data storage increase the convenience and functionality of these units.
With RS232, USB-A, USB-B, and Ethernet connectivity, Series balances are well suited to data export, and process integration.
The Series is available with internal or external calibration types. The internal automatic calibration and adjustment offers three internal calibration options: Temperature-activated, time- activated or manually activated calibration. The external calibration type prompts the user for the pre-defined mass to calibrate the mechanism, ensuring precise and repeatable measurements.
All Series balance combine state of the art features with premium build quality and reliability, all backed 5-Year Guarantee
| SKU | 222.GBT314 |
|---|---|
| Similar Products | GBT-314 |
Application Modes: Optimize the performance of your balance with one of 11 application modes: Basic Weighing, Piece Counting, Check Weighing, Dosing, Deviations, Density Determination (Solids & Liquids), Animal Weigh, Statistics, Totalizing (Formulation), and Peak Hold.
Premium Build Quality: The housing is designed to endure the most challenging environments from teaching labs to industrial use.
Database Storage and Onboard Processing: Standard on the Series balances. Store Users, Products, Weighings, Packaging, Formulations and Customers in memory. Detailed reporting includes Balance ID, User, Date, Time, Software Version, Measurement Mode, Results, and Signature Line, allowing for data stewardship and complete GLP documentation.
Touch-Screen Display: Intuitive interface navigation. Easily click, scroll, and tap through menus and submenus. Infrared sensors also allow for touchless operation, when cleanliness and compliance is at a premium.
User-Friendly Draft Shield: Standard on semi-micro and analytical models. The internal dimensions (16.0 x 16.8 x 23.0 cm (6.25 x 6.6 x 9”)). and three sliding doors allow for easy access to the chamber. The draft shield doors, stainless steel weigh pan, and draft chamber floor are easy to remove for cleaning. A short, removable draft shield comes standard on the 0.001g readability GBTSeries precision balances.
5-Year Replacement Guarantee: Long term support enables you to purchase with confidence.
Note: All instruments and names of manufacturers mentioned herein are the trademarks of their respective companies and are used for reference purposes only. Clinivex Inc. expressly disclaims any affiliation to them
| Advanced Touch Display Analytical & Precison Balances | |||||||
| Item # Item # (with Cal. Cert.)* | 222.GBT64 GBT64CT | 222.GBT164 GBT164CT | 222.GBT224 GBT224CT | 222.GBT314 GBT614CT | 222.GBT363 GBT363CT | 222.GBT603 GBT603CT | 222.GBT1003 GBT1003CT |
| Maximum Capacity | 62 g | 160 g | 220 g | 310 g | 630 g | 600 g | 1000 g |
| Readability | 0.1 mg | 0.1 mg | 0.1 mg | 0.1 mg | 0.001 g | 0.001 g | 0.001 g |
| Linearity | +/- 0.2 mg | +/- 0.2 mg | +/- 0.2 mg | +/- 0.2 mg | +/- 0.002 g | +/- 0.003 g | +/- 0.003 g |
| Repeatability | 0.1 mg | 0.1 mg | 0.1 mg | 0.15 mg | 0.001 g | 0.0015 g | 0.0015 g |
| Calibration Type | External | ||||||
| Stabilization Time | 3 sec | 2 sec | 2 sec | 2.5 sec | 2 sec | 2 sec | 2 sec |
| Pan Size | ø 90 mm | ø 100 mm | ø 100 mm | ø 100 mm | 128 x 128 mm | ||
| Device Dimensions | 351 x 205.5 x 338 mm | 333 x 206 x 100 mm | 333 x 206 x 107 mm | ||||
| Ports | RS232, 2 x USB-A, USB-B, Ethernet | 2 x RS232, USB-A, USB-B, Ethernet | |||||
| Advanced Touch Display Analytical & Precision Balances | ||||||
| Item # Item # (with Cal. Cert.)* | 222.GBT2002 GBT2002CT | 222.GBT4502 GBT4502CT | 222.GBT6002 GBT6002CT | 222.GBT6001 GBT6001CT | 222.GBT10001 GBT10001CT | 222.GBT20001 GBT20001CT |
| Maximum Capacity | 2 kg | 4500 g | 6000 g | 6 kg | 10 kg | 20 kg |
| Readability | 0.01 g | 0.01 g | 0.01 g | 0.1 g | 0.1 g | 0.1 g |
| Linearity | +/- 0.03g | +/- 0.02 g | +/- 0.02 g | +/- 0.3 g | +/- 0.3 g | +/- 0.3 g |
| Repeatability | 0.015 g | 0.008 g | 0.008 g | 0.1 g | 0.08 g | 0.1 g |
| Calibration Type | External | |||||
| Stabilization Time | 2 sec | 1.5 sec | 1.5 sec | 2 sec | 2 sec | 2 sec |
| Pan Size | 195 x 195 mm | |||||
| Device Dimensions | 333 x 206 x 107 mm | |||||
| Ports | 2 x RS232, USB-A, USB-B, Ethernet | |||||
