Centrifuge, Hematocrit, 24-Place, 230v, 50Hz with EU Plug, 24-place rotor, reading disk

In stock
Centrifuge, Hematocrit, 24-Place, 230v, 50Hz with EU Plug, 24-place rotor, reading disk

  • The GCH-24 Hematocrit Centrifuge allows your lab to determine erythrocyte fractions in blood as well as micro solution separations using the included twenty-four (24) place capillary rotor.

  • The included rotor lids enhance user safety and are easy to remove or replace.

  • Programming is simple with the backlit LCD display, intuitive control buttons and parameter adjustment knob. The timer will not count down until the programmed speed is reached, ensuring accurate results.

  • Setpoint can be set by G-Force or RPM.

More Information
SKU GCH-24-EU

Features:

  • Speed range of 200-14,000rpm, max. RCF 18,620 x G

  • Independent control of speed and time

  • Easy operation with intuitive menu and easy-to-read display

  • Maintenance free brushless DC motor

  • Pulse operation for quick spins

  • Included hematocrit rotor: 24 capillary capacity, max. speed of 12,000rpm

  • Optional tube rotor: 24 place 1.5/2mL capacity, max. speed of 14,000rpm

  • Includes pulse operation (quick spin)


Advanced Features:

  • Speed/RCF switch

  • Short-time run function

  • Audible alert function


Safety Functions:

  • Door interlock

  • Overspeed detector

  • Over-temperature detector

  • Automatic internal diagnosis

  • Automatic rotor identification

Specifications GCH-24
Speed 200-14,000rpm in 10rpm increments
Maximum RCF 18,620 x G
Speed Accuracy +/- 20rpm
Run Time 30 sec - 99 min or continuous
Power 5A, 500W
Display Backlit LCD
Acceleration Time 30 sec
Braking Time 30 sec
Dimensions (WxDxH) 280 x 364 x 266mm (11.0 x 14.3 x 10.5")
Weight 10 kg (22lbs)
Certifications CE, cTÜVus, FCC, MCA
Warranty 2 Years
