Trinocular stereo zoom microscope Nexius, Zoom Evo,0.65x to 5.5x zoom obj,w/camera

In stock
Trinocular stereo zoom microscope Nexius

  • Experience the epitome of high-precision examination and three-dimensional imaging with the NexiusZoom EVO stereo microscopes.

  • Specifically engineered for your most demanding applications, these exceptional zoom microscopes provide unparalleled accuracy and clarity.

  • Whether analyzing material surfaces or observing and preparing biological samples, the NexiusZoom EVO is your gateway to comprehensive insights.

  • Binocular and trinocular heads with HWF 10x/22mm or HWF 10x/23mm eyepieces (EVO) for comfortable and immersive viewing experiences.

  • Double 3W LED illumination, ensuring optimal illumination for your specimens.

  • Large working distance, allowing ample space for sample manipulation and preparation.

  • Zoom ratio of 1:8.4, offering a remarkable magnification range from 6.5x to 55x. Capture the finest details and explore the microscopic world with precision.

  • Ergonomic stands designed to provide optimal comfort during extended observation sessions.

  • Configurations available with magnification capabilities up to 220x, catering to a wide range of applications.

  • CE certified, guaranteeing compliance with rigorous international standards for safety and quality.

  • Backed by a 10-year warranty, providing peace of mind and long-term support for your investment.

More Information
SKU 222.ENZ1703P​DC18
Similar Products ENZ-1703-P​-DC18

EYEPIECES

  • The NexiusZoom EVO series are supplied with a pair of HWF10x/23mm eyepieces

HEAD

  • Trinocular heads with 45° inclined tubes. Both eyepieces with ±5 diopter adjustments
  • Interpupillary distance adjustable between 54mm and 75mm. The trinocular head is supplied with a fixed light path beamsplitter (50:50).
  • The NexiusZoom EVO models are equipped with click-stops

 OBJECTIVES

  • The NexiusZoom EVO is supplied with a 1:8.4 plan achromatic zoom objective with 0.65x to 5.5x magnifications, a field of view from 35.4mm to 4.2mm. WD 110mm

All optics are anti-fungus treated and anti-reflection coated for maximum light throughput

MAGNIFICATIONS

Working distance and field of view with standard HWF 10x / 23 High Wide Field eyepieces of the NexiusZoom Evo:

STANDS

  • Ergonomically designed pillar or rack & pinion stand with 3W incident and 3W transmitted LED illuminations (-P and -S stands)
  • Ergonomically designed pillar stand with two 3W gooseneck type incident LED illuminations on each side and a 3W transmitted LED illumination (-PL stand)

All pillar and rack & pinion stands are supplied with two object clamps. Alloy metal cast, hardened coating

 ILLUMINATION

  • The 3W transmitted and incident LED illuminators with internal power supply 100-240VAC operation. Both illuminators can be used simultaneously, and the light intensities can be adjusted separately

APL (Antimicrobial Protection Layer)

  • Developed with a protective microbe-resistant coating, the NexiusZoom microscope series utilizes a revolutionary paint treatment that helps restrict the growth of microorganisms, including bacteria and mold, which makes it an ideal solution for any laboratory environment

PACKAGE CONTENT

  • Supplied with power cords, dust cover, a spare fuse, user manual. All packed in a polystyrene box



222.ENZ1703P

222.ENZ1703PG

222.ENZ1703S

Head

trinocular 45º inclined. 54-75mm interpupillary. +/-5mm diopter adjustment on both eyepiece tubes

trinocular 45º inclined. 54-75mm interpupillary. +/-5mm diopter adjustment on both eyepiece tubes

trinocular 45º inclined. 54-75mm interpupillary. +/-5mm diopter adjustment on both eyepiece tubes

Eyepiece

HWF10x/23mm

Focusing

Macro on both sides of the head holder

Objective

0.65x – 5.5x zoom with clip stop (6.5x – 55x)

Stage

Plain with clips, black/White and clear plates

Illumination

3W LED incident and transmitted simultaneously

3W LED incident by two gooseneck arms and transmitted simultaneously

3W LED incident and transmitted simultaneously

Stand

Pillar WD:110mm

Rack and pinion. WD:110mm





 Item #

Description

222.ENZ1703S​

Trinocular stereo zoom microscope NexiusZoom EVO, 0.65x to 5.5x zoom objective, magnification from 6.5x to 55x with rack and pinion stand.  Incident and transmitted 3 W LED illuminations

222.ENZ1703S​DC18

Trinocular stereo zoom microscope NexiusZoom EVO, 0.65x to 5.5x zoom objective, magnification from 6.5x to 55x with rack and pinion stand.  Incident and transmitted 3 W LED illuminations, with 18MP Camera

222.ENZ1703P​

Trinocular stereo zoom microscope NexiusZoom EVO, 0.65x to 5.5x zoom objective, magnification from 6.5x to 55x with pillar. Incident and transmitted 3 W LED illuminations

222.ENZ1703P​DC18

Trinocular stereo zoom microscope NexiusZoom EVO, 0.65x to 5.5x zoom objective, magnification from 6.5x to 55x with pillar. Incident and transmitted 3 W LED illuminations, with 18MP Camera

222.ENZ1703PG​

Trinocular stereo zoom microscope NexiusZoom EVO, 0.65x to 5.5x zoom objective, magnification from 6.5x to 55x with pillar. Two incident LED illuminations with Gooseneck and one transmitted 3 W LED illumination

222.ENZ1703PG​DC18

Trinocular stereo zoom microscope NexiusZoom EVO, 0.65x to 5.5x zoom objective, magnification from 6.5x to 55x with pillar. Two incident LED illuminations with Gooseneck and one transmitted 3 W LED illumination, with 18MP Camera
